NC Helical Blade Cut-off Machine

Double Layer Computerized Spiral Knife Corrugated Cardboard Cross-cutting Machine

Main technical features:

(1) Full AC servo control, energy storage brake, helical knife structure, oil-immersed gear transmission, 10.4-inch touch screen display.

(2) 200 groups of orders can be stored, the specifications of paper cutting can be changed quickly and accurately, the order can be changed without stopping, and the computer networking can be realized to facilitate production management.

(3) The drive gear of the cutter shaft adopts high-frequency quenching of precision forged steel material to realize backlash-free transmission. It adopts advanced keyless connection method and has high transmission precision.

(4) The blade of the cross-cutting machine adopts the structure of a steel spiral knife with a serrated blade. Scissor-type shearing, low shearing force and long blade life.

(5) The front and rear paper feeding rollers adopt the method of sun wheel pressing, which has stable conveying and uniform pressure, and is not easy to crush the board or cause blockage.

(6) This model is energy storage braking (non-energy-consuming braking), low energy consumption in the production process, the average power consumption is 1/3 of the ordinary NC cutting machine, saving more than 70% of electricity, to save money Target.

(7) Precisely adjustable backlash-free gears to ensure precise meshing of the blade and balanced operation.

(8) Oil bed type lubrication is used for oil supply, lubrication and cooling in each gear position.

(9) Knife roller: Made of high-quality precision forged steel, it is balanced and has good stability.

Technical parameter
